Sintered Mesh
Filter Cartridges
Engineered for extreme reliability, our sintered wire mesh cartridges offer unparalleled mechanical strength and precision filtration for critical high-pressure and high-temperature industrial processes.
Engineering Excellence
Our multi-layer sintered structure provides exceptional structural integrity without compromising permeability.
High Pressure Resistance
Sintered layers create a monolithic structure that resists deformation under extreme differential pressure environments.
Thermal Stability
Maintains precise pore geometry and mechanical properties across a wide temperature range up to 600°C (1112°F).
Corrosion Resistance
Available in SS316L, Monel, and Hastelloy for compatibility with aggressive chemical and offshore environments.
Technical Specifications
Precision data for engineering integration and system design.
| Parameter | Specification Range | Standard Compliance |
|---|---|---|
| Micron Rating | 0.5μm to 200μm (Absolute) | ISO 4572 / NAS 1638 |
| Standard Lengths | 10", 20", 30", 40" (Custom lengths up to 1500mm) | DIN Standard |
| Materials | SS304, SS316L, Alloy 20, Hastelloy C22/C276 | ASTM A240 |
| Outer Diameter | 25mm, 38mm, 50mm, 60mm, 65mm | ANSI Compatible |
| End Adaptors | DOE, 222/Flat, 226/Fin, Threaded NPT/BSP | Universal Fit |
Chemical
Filtration of corrosive solvents, polymers, and catalysts in high-demand chemical processing plants.
Oil & Gas
Critical sand control and produced water filtration for offshore and onshore extraction sites.
Built for the
Industrial Frontier
YD Filter's Sintered Mesh Cartridges are deployed in some of the world's most hostile environments. From chemical refinement to deep-sea oil extraction, our filters deliver consistent purity where failure is not an option.
Optimize Your Process Efficiency
Our engineering team is ready to assist you in selecting or custom-designing the perfect filtration solution for your specific requirements.
